IP66,12000N/1200KG/2620LBS,60mm/second,Potentiometer,Hall sensor,Encoder position feedback

OK-LA24  is cost-effective and reliable heavy duty linear actuator for harsh environment. robust metal gears and corrosion-resistant housings provides high force capabilities,up to 12000N/1200KG/2620LBS,max speed 60mm/second.

Main Specification


1	Type	OK-LA24 Linear Actuator
2	Input	12/24V DC power
3	Load	Max 12000N/1200KG/2640LBS
4	Stroke	Max 1000MM/80INCH
5	Speed	Max 60MM/S 2.4INCH/S
6	Limited switch	Yes,with
7	Duty cycle	25%
8	Tube material	Aluminum alloy or stainless steel
9	Color option	Black
10	Mounting bracket	Options
11	Control system	Options
12	Signal feedback	Hall sensor,Potentiometer,Encoder signal feedback,forward and reverse signal feedback
13	Manual	Manual function(it can work even no power)
14	Options	Both push/pull,only push,no pull. Overload,Overheat,Overcurrent protection.
15	Certificate	CE Rohs UL
16	Protection	Normal IP65 IP66
17	Customize	Yes


Speed&Load&Current


Type	Load/Force	Noload Speed MM/SECOND	12V current MAX A	24V current MAX A
A	12000N/1200KG/2640LBS	6.5	20	10.5
B	10000N/10000KG/2200LBS	13	20	10.5
C	7500N/750KG/1650LBS	13	19	9.5
D	7000N/700KG/1540LBS	17	19	9.5
E	6500N/650KG/1430LBS	20	19	9.5
F	5000N/500KG/1100LBS	25	19	9.5
G	4000N/400KG/880LBS	30	20	10.5
H	3200N/320KG/704LBS	38	20	10.5
I	3000N/300KG/660LBS	40	19	9.5
J	2000N/200KG/440LBS	60	20	10.5

DrawingFor example 100mm stroke  Lmin=200+Stroke=200+100=300mm=12inch
Lmin means the length when linear actuator 100% fully retracts, meanwhile,it will touch the tail limited switch,power automatic off and stop by itself.
2.  Stroke means the movement length of linear actuator.
3.  Normal extended length/From center of mounting holes
For example 100mm stroke   Lmax=Lmin+Stroke=300+100=400mm=16inch
Lmax means the length when linear actuator 100% fully extends, meanwhile,it will touch the head limited switch,power automatic off and stop by itself.
Built limited switch prevents over-retracting and over extending,safety.
