| Dynamic Load Push(N) | 4000 | 2000 |
| Dynamic Load Pull(N) | 4000 | 2000 |
| Dynamic Load Pull(N) | 4000 | 2000 |
| Static Load Pull*(N) | 4000 | 2000 |
| Input(VDC) | 24 | |
| Speed at Full Load(mm/s) | 4 | 9 |
| Input(VDC) | 12 | |
| Speed at Full Load(mm/s) | 3.5 | 5 |
| Stroke Length(mm) | 100~400(option>400) | |
| Mounting | By screws on the side directly or by holder (option) | |
| Colour | Black or Grey | |
| Limit Switch | Build-in | |
| Overload Protection | Yes | |
| Limit Switch | 10%, max, 2min. continuous use | |
| IP Grade | IP43 | |
| Operation Temperature | +5℃~ +40℃ | |
| Optional Feature | Hall sensor option | |
| Standard | CE /UL | |
